MSL-D Street Light
D street light introduction
Applicable places
urban expressway/main and secondary trunk roads, branch roads, factories, schools, parks, various residential areas, courtyards and other road lighting.
ITEM No. | MSL-D100 | MSL-D150 | MSL-D200 |
Power | 100w | 150w | 200w |
Lumionous Flux | >13000lm | >19500lm | >26000lm |
NW/Size(kg,mm) | 4.7kg/543*317*75mm | 4.8kg/543*317*75mm | 5.6kg/663*317*75mm |
ITEM No. | MSL-D240 | MSL-D300 | |
Power | 240w | 300w | |
Lumionous Flux | >31200lm | >39000lm | |
NW/Size(kg,mm) | 6kg/663*317*75mm | 6.8kg/785*317*84mm | |
CCT | 2700-6500k | PF Rate | >0.95 |
Material | Die-casting Aluminum+PC | CRI | >70 |
Life span | 50000h | LED lamp | SMD 3030 |
Luminous flux | 130lm/w | Guarantee | 3 years |
Product Features:
1: The D Series Street Light lamp shell adopts a newly designed high-quality all-aluminum street lamp shell. The appearance is simple and stylish. The appearance is anodized and electrostatic sprayed. The heat sink is integrated with the lamp shell. It is corrosion resistant and has good heat dissipation performance. The profile has large scattered area, beautiful appearance and good waterproof.
2: Shell structure: special D Series Street Light lamp shell structure design, so that the circulation of wind can speed up the heat dissipation effect, while reducing wind resistance, reducing the pressure load of the lamp pole, special mounting bracket structure design, the lamp arm can be adjusted in a wide range of angles and illumination angles It also becomes adjustable at will.
3: Structural waterproof function: The unique structure is conducive to the discharge of water on the shell. The new type of waterproof silica gel can ensure the airtightness of the lamp and ensure that no water and dust enter.
4: Superior extended support: Our D Series Street Light lights also have perfect support for sensors. It is possible to install light sensor probes on the top of the street lights to achieve the intelligent power saving effect of turning off the lights at dawn and turning on the lights at dark; Infrared sensor probes can be installed below the, to achieve the effect of automatically turning on the lights when a moving object passes by, and automatically turning off or dimming after a period of time.
MIC MSL-D Street Light
MIC D street light is characterized by simplicity, ease of use, light weight, and strong integration. The characteristics of our lamp determine its low price and low freight cost. The greatest benefit to customers.
