3.2v Lithium ion Lifepo4 Battery
lithium iron phosphate battery batteries accessories
Quick info
Cycle life: 7000 Times Nominal Capacity: 50/80/100/105/120/160/202/230/280/304/320Ah
Suitable for：Engine starting battery, electric bicycle/motorcycle/scooter, golf trolley/carts, power tools…Solar and wind power system, RV,
caravan
- Description
- Specification
| WithQR Code | Voltage | Capacity | Max Charge Current | Max Dis. Current | AC IR. | Weight | Dimension(mm) |
| Yes | 3.2V | 50Ah | 100A | 150A | ≤0.5mΩ | 1.5kg | H185*W135*T30 |
| Yes | 3.2V | 80Ah | 80A | 240A | ≤0.5mΩ | 1.7KG | H170*W130*T36.7 |
| Yes | 3.2V | 100Ah | 50A | 300A | ≤0.5mΩ | 2kg | H118.5*W160*T50 |
| Yes | 3.2V | 105AH | 105A | 315A | ≤0.15mΩ | 2kg | H196*W130*37 |
| Yes | 3.2V | 120Ah | 240A | 120A | ≤0.5mΩ | 2.84kg | H166*W174*T48 |
| Yes | 3.2V | 160AH | 320A | 320A | ≤0.5mΩ | 3.0KG | H157*W174*T54 |
| Yes | 3.2V | 202AH | 100A | 200A | ≤0.25mΩ | 4.06kg | H173*T54*H209.6 |
| Yes | 3.2V | 230AH | 230A | 230A | ≤0.25mΩ | 4.2kg | H200*W173*T72 |
| Yes | 3.2V | 280AH | 280A | 280A | ≤0.25mΩ | 5.3kg | H208*W173*T72 |
| Yes | 3.2V | 304Ah | 300A | 300A | ≤0.25mΩ | 5.5KG | H200*W173*T72 |
| Yes | 3.2V | 302Ah | 300A | 300A | ≤0.25mΩ | 5.4KG | H206*W175*T73 |
 |
 |
3.2v Lithium ion Lifepo4 Battery
Suitable for：Engine starting battery, electric bicycle/motorcycle/scooter, golf trolley/carts, power tools…Solar and wind power system, RV,
caravan
Cycle life: 7000 Times
Nominal Capacity: 50/80/100/105/120/160/202/230/280/304/320Ah
 BMS |
 Flexible copper connections |
 |
 |
 |
 |
 |
 |
 UN3480 |
 Packing in wooden boxes |
